Intro #
We’ll build a linked list from the most basic idea: a list is a pair — a value and a pointer to the next pair. In JavaScript, a pair is just a two‑element array.
List as pairs (value, next):
+-----------+ +-----------+ +-----------+
| 1 | *---+---->| 2 | *---+---->| 3 | NIL |
+-----------+ +-----------+ +-----------+
- left cell is the stored value
- right cell is the pointer to the next pair (or NIL)
Empty first #
Every structure needs an end. We’ll use a JavaScript Symbol as a unique empty marker and return it from a tiny lambda.
const NIL = Symbol('list.nil');
const nill = () => NIL;
// Checks
console.assert(typeof NIL === 'symbol');
console.assert(nill() === nill(), 'nill must be stable');
Emptiness check uses the same sentinel for clarity and consistency.
const isEmpty = (list) => list === nill();
// Checks
console.assert(isEmpty(nill()));
console.assert(!isEmpty(undefined));
console.assert(!isEmpty(cons(0)));
Make a node #
What is a list node? Two slots: value and next. In JS, that’s a 2‑element array.
// A pair is [value, next]
const cons = (value, next = nill()) => [value, next];
// Quick check
const one = cons(1);
console.assert(
Array.isArray(one) &&
one.length === 2 &&
one[0] === 1 &&
one[1] === nill()
);
Default next = nill() means “this is a tail unless told otherwise”. The shape is explicit and visible in the console.
More constructions with multiple nodes:
// Nested construction (right‑associative)
const twoNodes = cons(1, cons(2)); // [1, [2, Symbol(list.nil)]]
const threeNodes = cons('a', cons('b', cons('c')));
console.assert(twoNodes[0] === 1 && twoNodes[1][0] === 2);
console.assert(
threeNodes[0] === 'a' &&
threeNodes[1][0] === 'b' &&
threeNodes[1][1][0] === 'c'
);
// Linking via intermediate variables
const third = cons(3);
const second = cons(2, third);
const first = cons(1, second);
console.assert(
first[1] === second &&
second[1] === third &&
third[1] === nill()
);
// Prepending step by step (build from the front)
let xs = nill();
xs = cons(3, xs); // [3, NIL]
xs = cons(2, xs); // [2, [3, NIL]]
xs = cons(1, xs); // [1, [2, [3, NIL]]]
console.assert(
xs[0] === 1 &&
xs[1][0] === 2 &&
xs[1][1][0] === 3
);
Read the first slot #
What is the use of the list if we cannot extract values from it? Let's do it in a safe manner.
const head = (list) => list === nill() ? undefined : list[0];
// Checks
console.assert(head(cons(42)) === 42);
console.assert(head(nill()) === undefined);
Returning undefined for empty avoids indexing into an empty marker while still signaling “there’s nothing here”.
Follow the pointer #
Remember the pair as a core of the list? Time to get to the second element (tail). It will give us the ability to move forward.
const tail = (list) => list === nill() ? nill() : list[1];
// Checks
const two = cons(2);
const pair = cons(1, two);
console.assert(tail(pair) === two);
console.assert(tail(nill()) === nill());
Returning the sentinel for empty aligns with our choice and keeps the traversal loop simple.
Traversing #
Traversal is the act of visiting each node in a list, one by one, starting at the first pair and following tail until we hit the empty sentinel nill(). Because linked lists do not support random access by index, traversal is the fundamental way to do anything non‑trivial with them: searching, counting, converting to arrays, mapping/transforms, and in many cases removing or reversing elements. In other words, traversal is the workhorse operation that other behaviors build on.
foldr (right fold) #
Right fold captures that traversal pattern as a reusable function that rebuilds a result as we return from recursion.
const foldr = (list, f, z) => {
const go = (p) => isEmpty(p) ? z : f(head(p), go(tail(p)));
return go(list);
};
sum:
Accumulate numbers by combining each element with the running total.
const sum = (list) => foldr(list, (x, acc) => x + acc, 0);
const xs = cons(1, cons(2, cons(3)));
console.assert(sum(xs) === 6);
sum starts with 0 and combines each element with the accumulator using x + acc. Because foldr returns f(head, foldr tail), addition is associative here, so result equals iterating left‑to‑right and summing by applying (x, acc) => x + acc as it returns from recursion.
mapF:
Rebuild a new list by applying g and consing onto the mapped tail, preserving order.
const mapF = (list, g) =>
foldr(list, (x, acc) => cons(g(x), acc), nill());
const ys = mapF(cons(1, cons(2, cons(3))), x => x * 2);
const arrY = [];
for (let p = ys; !isEmpty(p); p = tail(p)) {
arrY.push(head(p));
}
console.assert(JSON.stringify(arrY) === JSON.stringify([2,4,6]));
mapF rebuilds a new list by consing g(x) onto the accumulated mapped list. Using foldr ensures the original order is preserved: we compute the tail mapping first, then attach the current g(x) at the front.
filterF:
Keep elements that satisfy predicate by conditionally consing them onto the filtered tail.
const filterF = (list, predicate) =>
foldr(list, (x, acc) => predicate(x) ? cons(x, acc) : acc, nill());
const zs = filterF(cons(1, cons(2, cons(3))), x => x % 2);
const arrZ = [];
for (let p = zs; !isEmpty(p); p = tail(p)) {
arrZ.push(head(p));
}
console.assert(JSON.stringify(arrZ) === JSON.stringify([1,3]));
filterF conditionally conses x when predicate(x) is true; otherwise, it passes the accumulator through unchanged. Order is preserved for the same reason as mapF — we build the tail first and then decide whether to attach the current x.
foldrtraverses head → tail, but builds the result on the way back. Usingconskeeps order intact.Many helpers (like
map,filter,toArray) can be expressed viafoldr, keeping the iteration logic in one place.
toArray:
DevTools doesn’t know how to render our pair‑lists. Let’s convert to a plain JS array.
Loop version (explicit traversal):
const toArray = (list) => {
const out = [];
for (let p = list; !isEmpty(p); p = tail(p)) {
out.push(head(p));
}
return out;
};
console.assert(
JSON.stringify(toArray(cons(1, cons(2, cons(3))))) ===
JSON.stringify([1,2,3])
);
foldr version (expressed as a fold):
const toArrayF = (list) => foldr(list, (x, acc) => [x, ...acc], []);
console.assert(
JSON.stringify(toArrayF(cons(1, cons(2, cons(3))))) ===
JSON.stringify([1,2,3])
);
- The loop mirrors the core traversal shape and pushes as it goes — simple and efficient.
- The fold version encodes the same intent declaratively; it rebuilds the result as recursion unwinds. It’s concise but may allocate more intermediate arrays due to spreading.
Trees #
The list example might seem like an oversimplification. How about something more complex like a tree?
A binary tree is either empty or a node with three parts: left subtree, value, right subtree. We can model a node as a fixed‑shape triple (array with 3 elements): [left, value, right]. We’ll keep using the same nill() sentinel to represent the empty tree.
const tnode = (left, value, right) => [left, value, right];
const leaf = (value) => tnode(nill(), value, nill());
const isTreeEmpty = (t) => t === nill();
const leftOf = (t) => isTreeEmpty(t) ? nill() : t[0];
const valueOf = (t) => isTreeEmpty(t) ? undefined : t[1];
const rightOf = (t) => isTreeEmpty(t) ? nill() : t[2];
// Example tree: 2
// / \
// 1 3
const tree = tnode(leaf(1), 2, leaf(3));
console.assert(valueOf(tree) === 2);
console.assert(valueOf(leftOf(tree)) === 1);
console.assert(valueOf(rightOf(tree)) === 3);
Visualizing the same structure:
[ left , value , right ]
[ • , 2 , • ]
/ \
[ • , 1 , • ] [ • , 3 , • ]
Where "•" is the empty sentinel (nill()).
- Keeping nodes as plain arrays mirrors the list approach and makes DevTools inspection trivial.
leafis a convenience that fills both children with the empty sentinel.- If you prefer separate emptiness for trees, you could introduce a
const TNIL = Symbol('tree.nil')withtNill = () => TNILand swap it into the helpers above.
Tree traversal #
Tree traversal is visiting every node of the tree in a well‑defined order. Unlike lists (which have a single linear path), trees branch, so we must decide when to visit a node’s value relative to its children:
- Pre‑order: visit value, then left, then right
- In‑order: visit left, then value, then right (yields sorted values for BSTs)
- Post‑order: visit left, then right, then value
We’ll return our familiar pair‑list of values so the rest of the list tooling (like toArray) just works.
// Concatenate two pair-lists
const concat = (xs, ys) => isEmpty(xs) ? ys : cons(head(xs), concat(tail(xs), ys));
// In‑order: left, value, right
const inOrder = (t) =>
isTreeEmpty(t) ? nill() :
concat(
inOrder(leftOf(t)),
cons(valueOf(t), inOrder(rightOf(t)))
);
// Pre‑order: value, left, right
const preOrder = (t) =>
isTreeEmpty(t) ? nill() :
cons(
valueOf(t),
concat(preOrder(leftOf(t)), preOrder(rightOf(t)))
);
// Post‑order: left, right, value
const postOrder = (t) =>
isTreeEmpty(t) ? nill() :
concat(
postOrder(leftOf(t)),
concat(postOrder(rightOf(t)), cons(valueOf(t), nill()))
);
// Demo on 2
// / \
// 1 3
const t = tnode(leaf(1), 2, leaf(3));
console.assert(
JSON.stringify(toArray(inOrder(t))) === JSON.stringify([1,2,3])
);
console.assert(
JSON.stringify(toArray(preOrder(t))) === JSON.stringify([2,1,3])
);
console.assert(
JSON.stringify(toArray(postOrder(t))) === JSON.stringify([1,3,2])
);
This mirrors our list style: small, composable helpers (concat, cons, nill) and clear traversal definitions that make the order explicit.
Queue #
Since we already have lists, it would be a shame not to build on top of them.
Queues support FIFO (first‑in, first‑out) behavior: enqueue at the back, dequeue from the front. A simple, fast, purely functional implementation uses two pair‑lists:
front— elements ready to dequeue (in correct order)back— elements enqueued most recently (in reversed order)
When front becomes empty, we flip back into front by reversing it — amortized O(1) operations overall.
const Q = (front = nill(), back = nill()) => [front, back];
const isQEmpty = ([f, b]) => isEmpty(f) && isEmpty(b);
// Local reverse for lists
const reverse = (list) => {
let r = nill();
for (let p = list; !isEmpty(p); p = tail(p)) {
r = cons(head(p), r);
}
return r;
};
const rebalance = ([f, b]) => isEmpty(f) ? Q(reverse(b), nill()) : Q(f, b);
const enqueue = (q, x) => {
const [f, b] = q;
return Q(f, cons(x, b));
};
// Dequeue returns a pair [value, nextQueue] or undefined if empty
const dequeue = (q) => {
const [f0, b0] = rebalance(q);
if (isEmpty(f0)) return undefined;
return [head(f0), Q(tail(f0), b0)];
};
// queue -> JS array (front ++ reverse(back))
const toArrayQ = ([f, b]) => {
const a = [];
for (let p = f; !isEmpty(p); p = tail(p)) a.push(head(p));
const br = reverse(b);
for (let p = br; !isEmpty(p); p = tail(p)) a.push(head(p));
return a;
};
// Demo
let q = Q();
q = enqueue(q, 1);
q = enqueue(q, 2);
q = enqueue(q, 3);
console.assert(JSON.stringify(toArrayQ(q)) === JSON.stringify([1,2,3]));
let r = dequeue(q); const x1 = r[0]; q = r[1];
console.assert(x1 === 1);
console.assert(JSON.stringify(toArrayQ(q)) === JSON.stringify([2,3]));
q = enqueue(q, 4);
q = enqueue(q, 5);
console.assert(JSON.stringify(toArrayQ(q)) === JSON.stringify([2,3,4,5]));
This queue piggybacks on the primitives you already built (pair‑lists, cons, tail, nill()), keeps the data shape transparent for DevTools, and demonstrates how a small amount of structure yields practical abstractions.
BST #
General purpose trees are boring. BST maybe?
Binary Search Trees (BST) let us implement Set/Map over ordered keys using the same 3‑slot node [left, value, right] and nill() as empty. We’ll keep it explicit by passing a comparator cmp(a, b) that returns <0, 0, or >0.
Set (BST over keys):
const setHas = (cmp, x, t) =>
isTreeEmpty(t) ? false :
(cmp(x, valueOf(t)) === 0 ? true :
cmp(x, valueOf(t)) < 0 ? setHas(cmp, x, leftOf(t)) : setHas(cmp, x, rightOf(t)));
const setInsert = (cmp, x, t) => {
if (isTreeEmpty(t)) return leaf(x);
const v = valueOf(t);
if (cmp(x, v) === 0) return t; // no duplicates
if (cmp(x, v) < 0) return tnode(setInsert(cmp, x, leftOf(t)), v, rightOf(t));
return tnode(leftOf(t), v, setInsert(cmp, x, rightOf(t)));
};
const minNode = (t) => isTreeEmpty(leftOf(t)) ? t : minNode(leftOf(t));
const setRemove = (cmp, x, t) => {
if (isTreeEmpty(t)) return t;
const v = valueOf(t);
if (cmp(x, v) < 0) return tnode(setRemove(cmp, x, leftOf(t)), v, rightOf(t));
if (cmp(x, v) > 0) return tnode(leftOf(t), v, setRemove(cmp, x, rightOf(t)));
// delete this node
if (isTreeEmpty(leftOf(t))) return rightOf(t);
if (isTreeEmpty(rightOf(t))) return leftOf(t);
// two children: swap with inorder successor
const m = minNode(rightOf(t));
return tnode(leftOf(t), valueOf(m), setRemove(cmp, valueOf(m), rightOf(t)));
};
// Demo
const byNumber = (a, b) => a - b;
let s = nill();
s = setInsert(byNumber, 2, s);
s = setInsert(byNumber, 1, s);
s = setInsert(byNumber, 3, s);
console.assert(setHas(byNumber, 2, s));
console.assert(JSON.stringify(toArray(inOrder(s))) === JSON.stringify([1,2,3]));
s = setRemove(byNumber, 2, s);
console.assert(JSON.stringify(toArray(inOrder(s))) === JSON.stringify([1,3]));
Map (BST over [key, value]):
We’ll store entries as [key, value] in the node’s middle slot. The comparator operates on keys.
const keyOf = (entry) => entry[0];
const valOf = (entry) => entry[1];
const mapLookup = (cmp, k, t) => {
if (isTreeEmpty(t)) return undefined;
const e = valueOf(t), c = cmp(k, keyOf(e));
if (c === 0) return valOf(e);
return c < 0 ? mapLookup(cmp, k, leftOf(t)) : mapLookup(cmp, k, rightOf(t));
};
const mapInsert = (cmp, k, v, t) => {
if (isTreeEmpty(t)) return tnode(nill(), [k, v], nill());
const e = valueOf(t), c = cmp(k, keyOf(e));
if (c === 0) return tnode(leftOf(t), [k, v], rightOf(t)); // replace
if (c < 0) return tnode(mapInsert(cmp, k, v, leftOf(t)), e, rightOf(t));
return tnode(leftOf(t), e, mapInsert(cmp, k, v, rightOf(t)));
};
const mapRemove = (cmp, k, t) => {
if (isTreeEmpty(t)) return t;
const e = valueOf(t), c = cmp(k, keyOf(e));
if (c < 0) return tnode(mapRemove(cmp, k, leftOf(t)), e, rightOf(t));
if (c > 0) return tnode(leftOf(t), e, mapRemove(cmp, k, rightOf(t)));
// delete node
if (isTreeEmpty(leftOf(t))) return rightOf(t);
if (isTreeEmpty(rightOf(t))) return leftOf(t);
const m = minNode(rightOf(t));
return tnode(leftOf(t), valueOf(m), mapRemove(cmp, keyOf(valueOf(m)), rightOf(t)));
};
// Demo
let m = nill();
m = mapInsert(byNumber, 2, 'two', m);
m = mapInsert(byNumber, 1, 'one', m);
m = mapInsert(byNumber, 3, 'three', m);
console.assert(mapLookup(byNumber, 2, m) === 'two');
// In‑order over entries; project keys to show order
const keys = []; for (let p = inOrder(m); !isEmpty(p); p = tail(p)) keys.push(keyOf(head(p)));
console.assert(JSON.stringify(keys) === JSON.stringify([1,2,3]));
m = mapRemove(byNumber, 2, m);
const keys2 = []; for (let p = inOrder(m); !isEmpty(p); p = tail(p)) keys2.push(keyOf(head(p)));
console.assert(JSON.stringify(keys2) === JSON.stringify([1,3]));
This keeps BSTs aligned with our earlier primitives: arrays for nodes, nill() as empty, and small helpers. The comparator makes ordering explicit and testable in DevTools.
Graph #
Graphs connect values by edges. We’ll model a directed graph as an adjacency list: a pair‑list of entries where each entry is [node, neighbors], and neighbors is a pair‑list of nodes.
// Helpers
const contains = (xs, x) => {
for (let p = xs; !isEmpty(p); p = tail(p)) {
if (head(p) === x) return true;
}
return false;
};
const gNeighbors = (g, v) => {
for (let p = g; !isEmpty(p); p = tail(p)) {
const e = head(p);
if (e[0] === v) return e[1];
}
return nill();
};
const gInsertVertex = (g, v) => {
const go = (p) => {
if (isEmpty(p)) return cons([v, nill()], nill());
const e = head(p);
return (e[0] === v) ? p : cons(e, go(tail(p)));
};
return go(g);
};
const gSetNeighbors = (g, v, ns) => {
if (isEmpty(g)) return cons([v, ns], nill());
const e = head(g);
if (e[0] === v) return cons([v, ns], tail(g));
return cons(e, gSetNeighbors(tail(g), v, ns));
};
// Add a directed edge v -> w (ensures vertices exist)
const gAddEdge = (g, v, w) => {
let g1 = gInsertVertex(g, v);
g1 = gInsertVertex(g1, w);
const ns = gNeighbors(g1, v);
const ns1 = contains(ns, w) ? ns : cons(w, ns);
return gSetNeighbors(g1, v, ns1);
};
// BFS (returns pair-list of visited nodes)
const reverse = (list) => { let r = nill(); for (let p = list; !isEmpty(p); p = tail(p)) r = cons(head(p), r); return r; };
const bfs = (g, start) => {
const Q = (front = nill(), back = nill()) => [front, back];
const rebalance = ([f, b]) => isEmpty(f) ? [reverse(b), nill()] : [f, b];
const enqueue = ([f, b], x) => [f, cons(x, b)];
const dequeue = (q) => { const [f0, b0] = rebalance(q); return isEmpty(f0) ? undefined : [head(f0), [tail(f0), b0]]; };
let q = enqueue(Q(), start);
let seen = nill();
let orderRev = nill(); // accumulate reversed
for (let step = dequeue(q); step !== undefined; step = dequeue(q)) {
const node = step[0]; q = step[1];
if (!contains(seen, node)) {
seen = cons(node, seen);
orderRev = cons(node, orderRev);
for (let ns = gNeighbors(g, node); !isEmpty(ns); ns = tail(ns)) {
q = enqueue(q, head(ns));
}
}
}
return reverse(orderRev);
};
// Demo graph: 1 -> 2, 1 -> 3, 2 -> 4
let G = nill();
G = gAddEdge(G, 1, 2);
G = gAddEdge(G, 1, 3);
G = gAddEdge(G, 2, 4);
const order = []; for (let p = bfs(G, 1); !isEmpty(p); p = tail(p)) order.push(head(p));
console.assert(JSON.stringify(order) === JSON.stringify([1,2,3,4]));
This keeps graphs in the same spirit: pair‑lists everywhere, tiny helpers, and a BFS implemented with the same queue idea — all easy to inspect in DevTools.
Conclusion #
Craft is clarity. A list can be just pairs: [value, next]. With nothing but DevTools, you can design, test, and refine the API before any framework or IDE enters the room. Patterns come later — after you’ve understood the shape of the problem.
Source code #
Reference implementation (opens in a new tab)
